Designated for surface and pre-sowing soil processing and fallowing to a depth of 6 to 15 cm.
The presented equipment processes the soil for spring, vegetable and row crops, is perfect for fallow fields, stubble backgrounds, as well as for pre-sowing loosening of the top layer of soil. Adapted to work in different soil and climatic conditions and have unique technical specifications.
The 5 rows of duckfoot tines, optimally spaced on the frame, ensure the unimpeded passage of large amounts of crop and harvested material through the cultivator. The tine arrangement minimizes the buildup of wet soil on the wheels and has a positive effect on the plow uniformity.
Three-section models are available with operating coverage width of 8.2/10.2/12.2 m for 210 to 350 hp tractors, and five-section models 14.8 m and 18.3 m for 350 ... 530 hp tractors.
- Description
- Technical parameters
- Video (2)
- Ask a question
-
Quality advantages of cultivators series R
Robust frame
Cultivator frame is tremendously rigid and durable, thanks to the use of shaped tubes with a section of 120x80x7 mm. Tubes are made of alloy steel and welded together in inert gases according to a well-proven technology.
Clearance
High under-frame clearance of 68 cm allows the cultivator to work on fields with a lot of weeds and stubble residues. A road clearance of 38 cm under the duckfoot tine in the transport position provides easy maneuvering on headlands and at crossings.
Reinforced duckfoot tine stand
The powerful C-shaped tine has a permissible tripping limit of 250 kg, which ensures a stable stroke of the duckfoot tine even in the tractor's tracks, which is important for seedbed preparation.
Floating hitch tongue
A floating hitch tongue and front passing wheels ensure ground contour following. In contrast to models with a rigid coupler, the R series cultivators provide a more stable working depth.
Combined loop
The cultivator loop, consisting of three rows of spring harrows and a roller with active slats, levels the surface of the field.
Passing wheels
Front passing wheels increase the mobility of the wide-cut implement.
Processing depth adjustment
The frame design has individual adjustment in the center and on the wings of the cultivator, which allows an equal working depth across the operating coverage width, regardless of the degree of immersion of the support wheels into the soil.
Surface leveling
Three-row spring harrows with 495 ×11 mm tine size, are individually adjustable. Each row of tines operates at a different approach angle: 20°, 25°, 30° and at different depths. This ensures optimal surface leveling. -
Specifications Model R-820 R-1020 R-1220 R-1480 R-1830 Type Trailer Tractor-mounted Operating coverage width, m 8,2 10,2 12,2 14,8 18,3 Performance, ha/h, up to 9,8 12,2 14,6 17,7 21,9 Processing depth, cm 6...15 Number of operating elements, pcs 33 40 48 58 72 Setting increment of duckfoot tines, mm 254 Duckfoot tine operating coverage width, mm 305 Operating force of the operating element stand, kgf, max 250 Number of loop modules 4 6 Diameter of spring tines, mm 11 Cutting of weeds, % 100 Deviation of the average depth from the target depth, cm ±2 Ridgeness of the soil surface, cm, max
- soil processing at 6...12 cm
- soil processing at 10...15 cm
4
5Required tractor power, hp/meter 25…35 Aggregated with tractors with engine power, hp 210...280 250...350 250...350 350...420 420...530 Loop type Combined Weight (structural), kg, max 4 100 6 700 8 300 10 500 12 000 Transport clearance, min., mm 360 300 Operating speed, km/h, max 12 Traveling speed, km/h, max 10 Max. overall dimensions, mm:
- length
- width
- height
7 700
8 500
1 500
8 700
10 500
1 500
9 260
12 300
1 500
10 600
15 200
1 950
10 600
18 700
1 950 -
-
